Specialist rebuilds and reconditioned replacements for the 2.2 TD4 and 224DT diesel, trusted by Freelander 2, Evoque and Defender owners across Essex and the UK.
OWNER STORIES
Genuine feedback from customers whose 2.2 TD4 and Puma diesel engines were rebuilt, replaced or diagnosed at our workshop in Grays.
“My Freelander 2 lost power and threw EGR fault codes constantly. Rather than just clearing them, the team traced the underlying problem, rebuilt the top end and replaced the valve. Six months on, it pulls like new.”
Karen W.
Freelander 2
“The timing belt on my 2.2 TD4 had never been changed at 130,000 miles. They caught it during diagnostics, rebuilt the engine after inspection revealed wear, and probably saved me from a catastrophic failure.”
James H.
Freelander 2
“Sourced and fitted a reconditioned 224DT for my Evoque after injector seal leaks wrecked the original. Straightforward communication, a proper written warranty, and the car was back with me inside a fortnight.”
Tony M.
Evoque SD4
| Make | Model | Engine Code | Actual CC | Power KW / HP | Year Range | |
|---|---|---|---|---|---|---|
| Land Rover | Freelander 2 | 224DT | 2179 | 110 kW / 150 hp | 2006–2014 | Get Quote |
| Land Rover | Freelander 2 | 224DT | 2179 | 140 kW / 190 hp | 2006–2014 | Get Quote |
| Land Rover | Defender (Old) | ZSD-422 Ford Duratorq (Puma) | 2198 | 90 kW / 122 hp | 2007–2016 | Get Quote |
| Land Rover | Discovery Sport | 224DT / 2.2 TD4 | 2179 | 110 kW / 150 hp | 2014–2015 | Get Quote |
| Land Rover | Discovery Sport | 224DW / 2.2 SD4 | 2179 | 140 kW / 190 hp | 2014–2015 | Get Quote |
TWO DECADES OF FIXINGTHIS ENGINE'S WEAK POINTS
The 2.2 diesel is fundamentally strong, but two service items decide whether it reaches high mileage, and we address both on every job.
Timing Belt Renewed Ahead of Failure
EGR and Inlet Carbon Removed Completely
Your engine is dismantled to its last bolt, measured against original tolerances, then rebuilt with new bearings, piston rings, seals, belt kit and gaskets, giving a Freelander, Evoque or Defender drivetrain genuinely dependable second life.
When a crankshaft has run its bearings or a snapped belt has destroyed the valvetrain, rebuilding the original unit is not always economical. We keep tested, reconditioned 224DT engines in stock, available as bare units delivered UK-wide or fully installed at our Grays workshop with warranty included.
One phone call gets you a clear diagnosis and an itemised written price.
2.2 DIESEL ENGINE CAREMost 2.2 TD4 failures trace back to neglected servicing rather than poor design. The cambelt is the critical item: owners often assume it lasts the vehicle's lifetime, and when it lets go, pistons meet valves and the engine is destroyed in seconds.
EGR contamination is the everyday complaint, rough idle, black smoke, sudden limp-home mode and recurring fault codes.
Beyond those, we regularly see leaking injector seals baking carbon around the injector bodies, tired turbochargers on higher-mileage SD4 units, and blocked DPFs on cars used mainly for short journeys.
Main dealers rarely rebuild this engine; they quote for complete new units at prices that often exceed the vehicle's value. Our approach is different, we repair what can be repaired and replace only what measurement proves is worn.
Each engine is crack-tested and pressure-tested before assembly, and every ancillary known to fail, belt kit, water pump, EGR valve, injector seals, is renewed as standard.
The same workshop also handles diagnostics, head gaskets, turbo replacement, clutch and gearbox work, DPF replacement, engine swaps and major servicing, so your Land Rover never needs to visit two garages.
